LOADER : Kinds of JEDEC Tray 2-Stacker
with elevator : 120trays |
|
UN_LOADER |
|
1) Good tray stacker : 2-Stacker with elevator : 120trays
|
|
2) Rejct tray |
|
TRAY INDEX : Servo motor contrrolled
movement |
|
PACKAGE SORTING : 2-axis servo motor
controlled movement |
|
Automatic replacement of good and
reject package |
|
MARKING ZONE : Chamber type for removing
dusts |
|
DUST COLLECTOR |
|
Power : 1.5Kw |
|
정압 : 230mmAq |
|
INDEX TIME : 2sec. without vibration
|
|
UPH : 14K (u : 0.9) |
|
VISION SYSTEM : Hims Vision System
|
|
LASER SYSTEM : E-710DD(100W) |
|
SYSTEM SIZE : 1700mm(W)x2050mm(D)x1650mm(H) |
